Glass & Ceramics Industry Conveyor Systems
Materials that combine extreme hardness with brittleness, surfaces requiring protection from scratching or contamination, products that range from delicate to surprisingly heavy—the glass and ceramics industries present unique conveyor challenges. Since 1984, Custom Conveyor & Equipment Corporation has engineered material handling solutions for manufacturers working with these demanding materials.
Understanding Glass & Ceramic Material Properties
Successful conveyor design for glass and ceramics begins with understanding the seemingly contradictory properties these materials exhibit. A ceramic tile is hard enough to resist scratches from steel tools yet fragile enough to crack from point loads. Architectural glass is strong under distributed loads but vulnerable to edge impacts. Porcelain fixtures combine substantial weight with delicate features that chip easily.
Surface Protection Requirements
Glass and many ceramic products require conveyor contact surfaces that prevent scratching, marring, or contamination. Finished architectural glass cannot tolerate contact with abrasive materials. Decorative ceramics with glazed surfaces need protection during handling. Even unfinished glass and ceramic products often have surface quality requirements that influence conveyor design.
Custom Conveyor addresses these requirements through appropriate material selection for product contact surfaces. We engineer conveyors with belting, roller coverings, or support surfaces that protect product finishes while maintaining the structural integrity needed for reliable material handling.
Weight Considerations
While often associated with delicate handling, glass and ceramic products can be surprisingly heavy. Large architectural glass panels, ceramic sanitary fixtures, or tile products in bulk quantities require conveyors engineered for substantial loads.
Our fabrication capabilities support conveyor systems across the weight spectrum—from lightweight glass components weighing grams to heavy ceramic products approaching our capacity of 6 tons per unit. The 300-ton press brake in our Cedar Rapids facility enables forming of structural members appropriate for heavy glass and ceramic applications.
Thermal Expansion Properties
Glass and ceramic manufacturing often involves thermal processes. Products may enter conveyor systems at elevated temperatures or require controlled cooling during transport. Thermal expansion coefficients of glass and ceramics differ from conveyor materials, requiring engineering attention to prevent stress concentration or product damage.
When thermal considerations are present, Custom Conveyor engineers conveyor systems that accommodate temperature differences, allow for differential expansion, and protect both products and conveyor components from thermal effects.
Glass & Ceramics Manufacturing Sectors
Architectural & Flat Glass
Window glass, mirror products, architectural glazing, and other flat glass applications require conveyors that handle large, flat panels without inducing stress or causing surface damage. Products may travel horizontally on belt or roller systems, or vertically through processing equipment.
Flat glass conveyors must provide even support across panel surfaces, prevent point loads that could cause breakage, and protect edges where glass is most vulnerable. Custom Conveyor designs these systems with appropriate support spacing, proper product positioning features, and gentle transfer points between conveyor sections.
Container Glass
Bottles, jars, and other glass containers present different handling challenges than flat glass. Individual containers are relatively small and light, but production volumes can be extremely high. Products must be oriented correctly, moved at precise speeds, and handled without contact that could cause chips or cracks.
Container glass conveyors often incorporate specialized features for product orientation, spacing control, and gentle accumulation. We engineer systems that maintain production rates while protecting product quality throughout the handling process.
Ceramic Tile & Stone
Tile manufacturing involves products that are simultaneously hard and brittle, often with surface finishes requiring protection. Products range from small mosaic tiles to large format architectural pieces. Manufacturing processes may include drying operations, glazing, firing, and final finishing.
Tile handling conveyors must accommodate varying product sizes, provide appropriate support for tile thicknesses, and protect both glazed surfaces and fired edges. Custom Conveyor engineers conveyor systems that address these requirements while withstanding the abrasive nature of ceramic materials.
Sanitary Ceramics
Toilets, sinks, and other sanitary fixtures combine complex three-dimensional shapes with substantial weight and delicate features. These products require conveyors that provide stable support for irregular geometries while protecting glazed surfaces and thin-section areas from damage.
Sanitary ceramic conveyors often utilize fixtures or cradles designed for specific product shapes. We engineer these support systems based on the actual products being handled, ensuring stable transport without stress concentration or surface contact that could cause damage.
Technical & Advanced Ceramics
Electronic ceramics, cutting tool inserts, ceramic bearings, and other technical ceramic applications often involve smaller products with tight dimensional tolerances and high value-per-unit. These materials may be harder than steel yet remain vulnerable to edge chipping or surface contamination.
Technical ceramic conveyors require engineering attention to cleanliness, gentle handling methods, and precise positioning. Custom Conveyor designs systems appropriate for these demanding applications, incorporating features that protect high-value products throughout manufacturing processes.
Porcelain & Dinnerware
Fine china, porcelain products, and ceramic dinnerware combine decorative surface treatments with relatively thin cross-sections. Products must travel through multiple processing steps—forming, drying, glazing, decorating, firing—without damage to delicate features or applied finishes.
Porcelain handling conveyors balance throughput requirements with gentle handling needs. We engineer systems that maintain production efficiency while providing the careful product support these applications require.
Conveyor Engineering for Glass & Ceramics
Glass and ceramic applications demand conveyor designs specifically engineered for material properties and product characteristics. Generic material handling equipment rarely provides optimal solutions for these specialized industries.
Product Contact Surface Selection
The interface between conveyor and product determines whether handling preserves or damages product quality. Custom Conveyor selects contact materials based on product requirements—soft enough to protect surfaces yet durable enough for reliable long-term operation.
Belt materials might include specialized formulations that resist abrasion while providing non-marring contact. Roller coverings could incorporate materials that cushion products without compromising roller performance. Support surfaces may require specific textures or hardness values. We engineer these details based on your actual products and quality requirements.
Support Method Engineering
How products are supported during transport significantly affects both handling success and conveyor durability. Glass and ceramic products may require continuous support to prevent sagging or flexing, or specific support point locations to avoid stress concentration.
Our engineering approach analyzes product geometry, weight distribution, and structural properties to determine appropriate support methods. This might involve closely-spaced belt support, specific roller configurations, or custom fixtures designed for particular product shapes.
Transfer Point Design
Products moving between conveyor sections, entering or exiting processing equipment, or transitioning between different handling systems encounter conditions that can cause damage if not properly engineered. Glass and ceramics are particularly vulnerable at these transition points.
Custom Conveyor pays careful attention to transfer point design, ensuring smooth product transitions without shock loads, abrupt speed changes, or unsupported moments that could cause breakage. We engineer these details based on product characteristics and system requirements.
Speed & Acceleration Control
Fragile products require controlled acceleration and deceleration to prevent sliding, tipping, or stress during conveyor speed changes. Some glass and ceramic applications also require precise speed control for integration with processing equipment or to maintain product spacing.
We engineer drive systems and controls appropriate for your application requirements. This includes selecting motors and gearing that provide smooth operation, incorporating speed control when needed, and designing for integration with upstream or downstream processes.
Material Selection & Fabrication Capabilities
Different glass and ceramic applications require different conveyor materials and construction approaches. Custom Conveyor’s multi-material fabrication capabilities enable us to engineer and build conveyors appropriate for each application.
Stainless Steel Construction
Many glass and ceramic applications benefit from stainless steel conveyor construction. Corrosion resistance matters in environments with moisture from cleaning or cooling operations. Surface cleanliness requirements in certain applications favor stainless materials. Aesthetic considerations in visible production areas may specify stainless construction.
Our stainless steel welding and fabrication capabilities support complete conveyor system construction in various stainless grades. We select appropriate alloys based on environmental conditions, structural requirements, and application needs.
Carbon Steel for Industrial Applications
Glass and ceramic manufacturing environments without corrosive conditions or strict cleanliness requirements often utilize carbon steel conveyors with appropriate surface treatments. This approach provides cost-effective solutions while maintaining necessary structural performance.
Custom Conveyor’s carbon steel fabrication capabilities—including our 3kW fiber laser cutting system and 300-ton press brake—support conveyor construction from light-duty systems through heavy industrial applications. We apply appropriate coatings or surface treatments based on environmental requirements.
Aluminum Applications
Specific glass and ceramic handling applications benefit from aluminum conveyor construction. Weight-sensitive installations, corrosive environments, or situations requiring frequent conveyor relocation make aluminum attractive.
Our aluminum welding expertise allows us to engineer and fabricate aluminum conveyor systems that leverage the material’s properties while addressing its unique structural characteristics. The result is lightweight, corrosion-resistant conveyors appropriate for specialized glass and ceramic applications.
Application-Specific Engineering
Glass and ceramic conveyor projects rarely involve selecting from standard product catalogs. These applications require engineering based on actual product characteristics, process requirements, and facility constraints.
Define Your Need
Successful glass and ceramic conveyor projects begin with thorough understanding of your specific requirements. What products are you handling? What are the critical dimensions, weights, and surface requirements? What production rates must the conveyor support? What are the environmental conditions?
Custom Conveyor’s engineering process starts with these questions. We examine product samples when possible, review manufacturing processes, understand quality requirements, and identify facility constraints. This definition phase establishes the foundation for effective engineering.
Engineer A Solution
With detailed understanding of your application, our engineering team develops conveyor designs addressing your specific needs. This includes selecting appropriate conveyor types, determining construction materials, designing product support features, and engineering for integration with your facility and processes.
We provide engineering drawings and specifications detailing the proposed system. These documents allow review and verification that the design meets all requirements before proceeding to fabrication.
Deliver For You
Approved conveyor designs move to fabrication in our Cedar Rapids, Iowa facility. Our in-house manufacturing capabilities—laser cutting, press brake forming, welding across multiple materials, and assembly—transform engineering specifications into completed conveyor systems.
This integrated engineering and fabrication approach ensures accountability from initial concept through delivered system. The team that designs your glass or ceramic conveyor oversees its construction, maintaining quality control throughout the process.
Durability in Demanding Environments
While glass and ceramic products require gentle handling, the materials themselves are often highly abrasive to conveyor components. Glass dust from cutting operations, ceramic particulate from grinding or finishing, and general manufacturing environments affect conveyor durability.
Abrasion Resistance
Custom Conveyor engineers conveyors for glass and ceramic applications with understanding that these materials can be extremely abrasive despite requiring careful handling. Material selection for components exposed to product contact or environmental conditions includes consideration of abrasion resistance.
This might involve hardened rollers, abrasion-resistant belt materials, or protective treatments on structural components. We balance abrasion resistance with other requirements like product surface protection or structural performance.
Maintenance Accessibility
Conveyor systems operating in glass and ceramic manufacturing environments require periodic maintenance to sustain performance. Custom Conveyor designs with maintenance accessibility in mind, providing appropriate access for inspection, adjustment, and component replacement.
Well-designed maintenance access reduces downtime and extends conveyor service life. We engineer these features based on the specific maintenance requirements of each conveyor design and application.
Four Decades of Specialized Material Handling
Custom Conveyor & Equipment Corporation has been engineering conveyor solutions for specialized manufacturing applications since 1984. Glass and ceramics represent industries where generic material handling equipment often proves inadequate—where successful conveyor systems require engineering based on detailed understanding of material properties and application requirements.
Our experience with these demanding applications has developed our expertise in designing conveyors that handle fragile products reliably, protect critical surface finishes, and operate durably in challenging manufacturing environments. We understand the balance between gentle handling and robust construction that glass and ceramic applications require.
This application-focused engineering approach guides every glass and ceramics conveyor project we undertake. Whether you’re handling flat glass, ceramic tile, sanitary fixtures, or technical ceramic products, Custom Conveyor brings forty years of specialized material handling experience to your project.
Discuss Your Glass or Ceramics Handling Requirements
If you’re facing material handling challenges with glass or ceramic products—whether you need conveyors that protect delicate surfaces, handle products with complex geometries, or operate reliably in abrasive environments—Custom Conveyor & Equipment Corporation can help.
Our engineering team understands the unique requirements of glass and ceramics manufacturing. We invite you to discuss your specific conveyor needs with us. Call (319) 449-3322 or contact us through our contact page to start the conversation about engineering conveyor solutions for your glass or ceramics application.
